The radar calibration function needs to be performed in the following cases:
1. Automatically identify the model 500X through the ADAS calibration entrance VIN (If it is not recognized, the corresponding menu will be displayed, select manually and enter).
2. After selecting ADAS Calibration Function, click Radar Calibration.
3. Select Active Alignment Procedure: Radar Calibration.
4. Situations where the current function needs to be performed.
5. Preparations required to perform the current function.
6. Select according to the position of the current vehicle's radar sensor in the front of the vehicle, Click Next Step.
7. Follow the prompts, after the operation is complete, click Next Step.
8. Follow the prompts, after the operation is complete, click Next Step.
9. Follow the prompts, after the operation is complete, click Next Step.
10. Follow the prompts, after the operation is complete, click Next Step.
11. Follow the prompts, after the operation is complete, click Next Step.
12. Follow the prompts, after the operation is complete, click Next Step.
13. After completing the operation according to the prompt, click the calibration button to execute the calibration function.
14. Follow the prompts, after placing the target in position 1, click Next Step.
15. After completing the first part of the calibration, click Continue to perform the second part of the calibration.
16. Follow the prompts, after placing the target in position 2, click Next Step.
17. Complete the second part of the calibration, click Continue to perform the third part of the calibration.
18. Follow the prompts, after placing the target in position 3, click Next Step.
19. The third part of the calibration is complete, click Continue.
20. Turn off the ignition, wait for the progress bar (or countdown) to end, and then turn on the ignition.
21. Calibration is complete, please drive to verify that the radar is normal.
22. Print the report information after calibration.
