LANDROVER Range Rover Velar 2018 Camera Calibration

Apr 03,2023
Share :

Function Description:


The camera needs to be calibrated in the following cases:

1) IPMA system has fault code C1001-78 Vision System Camera – Alignment Or Adjustment Incorrect.

2) The gauges show that AEB is not available.


Operation guide:


1. Automatically identify the model Range Rover Velar (2018) through ADAS calibration entrance VIN.


range-rover-velar-forward-radar-calibration-01


2. After selecting "ADAS Calibration Function", click " LDW Front Camera Calibration".


range-rover-velar-forward-radar-calibration-02


3. Select "IPMA Set-up Application-camera Calibration".



4. Read the prompt carefully while the software is running, and click "OK "after confirming that it is correct.



5. According to the prompts, the battery voltage of the vehicle is required to be 12V. After confirming that it is correct, click "YES".



6. Follow the prompts, turn on the ignition switch, and click "OK".



7. After waiting for the module initialization process for 10 seconds, it will automatically jump to the next interface.



8. Read the operating conditions of the program carefully, and click “OK” after confirming that it is correct.



9. After waiting for the module initialization process for 20 seconds, it will automatically jump to the next interface.



10. Carefully read the operating conditions of the program. The current vehicle speed must be greater than or equal to 30kph. When the Percentage Complete column reaches 100%, the calibration is completed and the interface will automatically jump.



11. Camera calibration completed successfully.



12. Print the report information after calibration.
