ET30, a type of high-precision non-destructive leak testing equipment for EV Batteries, which mainly uses compressed air as medium to exert certain pressure on the inner cavity or outer surface of the product to be tested, and then uses high-sensitivity sensors to detect the change of pressure, so as to determine the sealing performance of the product to be tested.
contact
Video introduction to SmartSafe ET30 Leak Testing Detector for EV Batteries. Click on the video training center to view more case videos!
ET30 is mainly used for the leakage test of battery packs.
Working condition: No corrosive, no explosive, no electrical breakdown air or conductive dust.
|
Functions |
Description |
√ |
| Low-Pressure Airtightness Testing |
Using compressed air as the medium, a certain pressure is applied to the battery pack cavity, and a highly sensitive sensor detects pressure changes to determine its sealing |
√ |
|
Parameter Setting |
Pre-settable parameters include workpiece number, volume, pressure, duration for each stage, leakage limit, and other settings |
√ |
|
Process Visualization |
Real-time display of the working status during stages such as inflating, pressure stabilization, leakage testing, and exhaust |
√ |
|
Dual Pressure Value Display |
Real-time display of the current pressure and leakage fluctuation amount |
√ |
|
Historical Records |
Automatically save historical airtight records, support curve chart data display, support historical data export to USB flash drive in Excel file or share data overview in PDF file via email or QR code. |
√ |
|
Online Upgrade |
Supports online upgrade of devices, no need to use USB flash drive for local upgrade. |
|
|
Power Input |
AC90V~264V/40-60Hz |
Power |
20W Max |
|
Test Pressure Range |
0~30Kpa |
Air Source Requirements |
0.1~1.0 Mpa Dry Compressed air |
|
Sensor Resolution |
1pa |
Airlnlet Interface / Test Interface |
Φ6mm air pipe/Φ6mm air pipe |
|
Test Accuracy |
土5pa |
Working Temperature |
-10~ 55°C |
|
Interface |
RJ45×1/USB×2 |
Working Humidity |
10%~90% |
Do not allow water to enter the product.
When your hands are very oily, please do not touch the product.
Wipe the product with alcohol regularly.
In order to prevent the product screen from being scratched, a protective film can be attached to the product.
Prevent the product from being unresponsive due to the wrong wiring of the product.
