Functions |
Description |
√ |
| Battery Pack Detection |
Support battery pack detection of passenger car and commercial vehicle battery brands, read SOC/SOH, monomer/module voltage, temperature, battery pack status and fault information, and automatically calculate total voltage and differential pressure, key index data such as the highest/lowest voltage, and automatically mark abnormal data
|
√ |
|
Vehicle Detection
|
Support the whole system and full-function detection of EVs, such as code reading, code clearing, data flow reading, action testing, and special functions
|
√ |
|
Fast Charging Port Detection
|
Connect the fast charging detection gun with Bluetooth, and read the battery pack data through the fast charging port of the vehicle to realize fast detection of the battery pack
|
√ |
|
Maintenance Function
|
Support offline testing of DC-DC converters, OBC car chargers, air conditioner compressors, 48V light hybrid components, etc., and support 30+ common special functions
|
√ |
|
ADAS Calibration
|
Supports ADAS system calibration of many models in Europe, America, Asia, and China, compatible with ADAS PRO+, ADAS MOBILE, ADAS LITE, ADAS RADAR 3IN1 and other equipment
|
√ |
|
Test Report
|
Support the display of battery pack test report, vehicle test report, ADAS calibration report, etc
|
√ |
|
Software Upgrade
|
Support online upgrades, including model software, firmware software, and APP software
|
√ |
|
Module Expansion
|
Support tread detection, digital power supply, oscilloscope, multimeter, current clamp, insulation test, endoscope and other functional expansions
|
|
| Host | VCI | ||
|---|---|---|---|
| Display Size | 10.1inches(1920x1200) | Voltage | DC9~36V |
| CPU | 2.0GHz Octa-core | CPU | Cortex-A7 + Cortex-M7 |
| Memory | 4GB | Memory | 256MB |
| Storage | 128GB | Storage | 8GB |
| System | Android11 | System | Linux |
| Wi-Fi | 2.4GHz/5GHz | Wi-Fi | 2.4GHz/5GHz |
| Camera | Front 8MP, Post 13MP | Communication | Wi-Fi, BT, USB |
| Battery | 3.8V/9360mAH | Interface | USB Type B, OBDⅡ-16, DC-IN |
| Interface | Type A, Type C | Product Size | 197×40×83mm |
| Communication | Wi-Fi, BT, USB |
|
|
| Product Size | 318×40.5×246.5mm |
|
|
Do not allow water to enter the product.
When your hands are very oily, please do not touch the product.
Wipe the product with alcohol regularly.
In order to prevent the product screen from being scratched, a protective film can be attached to the product.
Prevent the product from being unresponsive due to the wrong wiring of the product.
